Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | ZTE NR8250 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Name: | NR8250 | Application: | Telecom Comunication |
|---|---|---|---|
| Warranty: | 1 Year | Port: | Shenzhen |
Overview
ZTE’s unified SDR-based hybrid microwave radio system NR8250 can be deployed for 2G/3G/LTE mobile backhaul network. The 2U height equipment supporting up to 6 radio directions has 8 slots that supports hot-swapping boards. In addition, the core unit and tributary unit boards support flexible configuration. NR8250 is applied to not only hybrid network (2G&3G), but also packet LTE network.
| NR8250 IDU Board Description | |||
| Board Type | Board Name | Board Description | Available Slots |
| RCU | RCUA | Radio Core Unit A | Slot 1 |
| RMU | RMUB | Radio Modem Unit B | Slots 3–8 |
| RTU | RTUA | Radio Traffic Unit A (16E1) | Slots 2–8 |
| RTUB | Radio Traffic Unit B (8×E1+1×STM1+1×STM1/4) | Slot s 2–8 | |
| RTUMO | Radio Traffic Unit Module Optical (2 x GbE(O)+4 x FE) | Slots 2–8 | |
| RTUME | Radio Traffic Unit Module Electrical (2 x GbE(E)+4 x FE) | slot 2–8 | |
| PM | PM | Power Module (for IDU) | slot 10–11 |
| RPU | RPUA | Radio Power Unit A (for ODU) | slot 12 |
| RFA | RFAA | Radio Fan A | slot 9 |
Benefits
ACM & ATPC Technologies to Enhance the Service Availability
Intelligent QoS Mechanism for Service Management
Network and Equipment Protection
Double Capacity with CCDP & XPIC
Hybrid & Native Platform
Promote Throughput with Frame Header Compression Technique
Header compression technique can reduce the cost of L2&L3 header to improve the transmission efficiency up to 2.25 times.
Digital Nodal Solution
Diversified Synchronization Methods without GPS Requirement
ACM Technology Reduces TCO
Smooth Network Evolution
Unified NMS
In Order to Save the Investment & Improve the maintenance efficiency, ZTE Provides a Unified Network Management System, which could manage the Microwave, RAN and other ZTE equipments universally.
Summary
ZTE NR8250 equipment has been applied in Poland Aero2, 2K Romania, Egypt Etisalat, Nigeria GLO and other operators, totally more than 8000 hops by 2011.
ZTE microwave product line is aim at offering low cost and high returns network to our global customers.
|
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei & ZTE & Cisco & Fiberhome & H3C & Ericsson & Alcatel Lucent & Emerson with Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.we can provide Plenty of Stock, Fast Delivery, Better price, and original guarantee.
Most of our technical engineers has considerable experience in company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
